How To Replace The Lining Plate Of Hydraulic Cone Crusher?

1. hanging out of an eccentric sleeve to grinding straight tapered bushing and bushing wear parts, to ensure that the friction surface finish.



   2. moving cone copper sleeve and the eccentric sleeve bushing, first check the moving cone cone diameter and eccentric sleeve diameter is up to the standard, and then install the new bushing.



   3. when installing a new copper sleeve, cool the new copper sleeve with dry ice or liquid nitrogen for at least 2 hours, and load it into the cone and the eccentric sleeve freely, without hammering or pressing



   4. install the moving cone assembly and the eccentric sleeve assembly before cleaning the outer wall of the eccentric sleeve and the main shaft. After the replacement, the running in must be carried out according to the operating rules



   5. adjust the size of the crusher bevel gear tooth gap and backlash. Adjustable backlash by increasing or decreasing the gasket of the thrust bearing.



   6. horizontal shaft blower cleaning filter, filter clogging or dust from entering the crusher, pollution of lubricating oil.



   7. check temperature sensors, pressure sensors, gear gauges, level gauges, sensors and hydraulic stations. Press the button box to work properly. If damaged, replace it



   However, in the assembly of cone crushers lining plate, first moving cone matter generates pretension force and spindle thread fastening liner with a stop gear is fixed, and then poured on the liner filled with zinc buffering equipments, prevent the liner fragmentation.



                  Click to view cone crusher parts introduction

Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd, specializing in the production of domestic and foreign brands of crusher wear spare parts manufacturers, production of domestic brands, Hua Yang, Shan Bao, SBM brands such as crusher wear parts, spare parts, as well as foreign brands, common, Sandvik, TEREX and other import brands crusher spare parts, wear parts, mining quarry companies such as crusher wear parts of choice. We achieve cost-effective localization of imported spare parts, service users at home and abroad. The company can be matched with various brands of hydraulic crusher electric parts, sealing parts, standard parts and other accessories, can meet the needs of one-stop shopping for customers at home and abroad the demand.



Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd has thirty years of production experience, and years of experience in processing export products, products have been exported to the United States, Canada, Australia, Sweden, Finland, Russia, Ukraine and Southeast Asia and other countries and regions. Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd product using the original material, high-quality raw materials, casting and heat treatment process we have a unique thirty years production experience, to ensure complete interchangeability, and original spare parts with high quality and competitive price, provide quality products, quality services for the majority of users.



Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd wearable parts can be customized to map, and if there is no map, the company has professional mapping personnel to help you mapping, after customization
