Lubrication Hydraulic Assembly Of common Cone Crusher-HP400

Hunan Fengwei Wear Parts Foundry is dedicated to all kinds of crusher wear resistant materials. Today we will talk about common HP400 lubrication hydraulic assembly steps



Connect the lubricating oil pump to the connecting housing



Connect connector to pump shaft



The rubber seal is arranged in the connecting housing



Drop the pump / connecting housing assembly through the holes in the plate



Secure the oil pump / connecting housing assembly to the plate with a bolt



The magnetic tube is fixed on the pump suction part



Position the motor vertically and place the motor shaft in the connector



The motor is fixed on the connecting casing



Place the rubber seal under the filter so that it passes down the hole of the press plate



Fix the filter on the pressure plate



Connect the pump outlet to the filter inlet with hoses and fittings



Lower oil level gauge and secure oil level gauge and seal on the pressure plate



Screw the air cleaner on the air pipe

         [ Click to view cone crusher parts introduction](/uploads/180725/2-1PH5120053B6.jpg)

Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd, specializing in the production of domestic and foreign brands of crusher wear spare parts manufacturers, production of domestic brands, Hua Yang, Shan Bao, SBM brands such as crusher wear parts, spare parts, as well as foreign brands, common, Sandvick, TEREX and other import brands crusher spare parts, wear parts, mining quarry companies such as crusher wear parts of choice. We achieve cost-effective localization of imported spare parts, service users at home and abroad. The company can be matched with various brands of hydraulic crusher electric parts, sealing parts, standard parts and other accessories, can meet the needs of one-stop shopping for customers at home and abroad the demand.

Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd has thirty years of production experience, and years of experience in processing export products, products have been exported to the United States, Canada, Australia, Sweden, Finland, Russia, Ukraine and Southeast Asia and other countries and regions. Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd product using the original material, high-quality raw materials, casting and heat treatment process we have a unique thirty years production experience, to ensure complete interchangeability, and original spare parts with high quality and competitive price, provide quality products, quality services for the majority of users.

Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd wearable parts can be customized to map, and if there is no map, the company has professional mapping personnel to help you mapping, after customization

Contact:Sales Director: Eileen Cai ;

      Email: sales@qrmech.com;

      Mobile telephone: +8618973821771

Fix the one-way valve at the outlet of the lubricating oil filter. The arrow shows the installation direction
