Sandvik CS Cone Crusher

Crusher ready to start work before a good habit of checking to ensure the normal operation of the perennial crusher is good. The regular maintenance and documented correctly, can not rely on memory. Pre startup and maintenance routine can reduce parking time, prolong life. Crusher crusher should be prepared before the start of the following preparations:



1, Check the lubricating oil lubrication system part of the installation is correct, according to the requirements.



2, The oil pump is driven solely by the motor, to start the pump. Open the tank above the tank inspection cover, check the oil return pipe, oil has been confirmed in the cycle. During normal operation, the discharge of oil for at least half of the discharge pipe.



3, If the crusher is equipped with an integral type crusher driven oil pump, the pump must start before oil filling, crusher, shaft bracket must be filled with oil. Remove the pump three through the pipe plug, into a certain amount of oil to the oil pump. This method is only used in the initial start-up and the longer time interval after the start. Under normal conditions, the one-way valve on the tank will be filled with oil pump to maintain in the state. The top of the hose apart shaft bracket, the shaft bracket is full of oil, and then put on the hose, then head. Originally started with this type of pump, in order to make the transmission sleeve of good lubrication, shaft bracket must be filled with oil.



4, Remove and squeeze in the broken liner between wedges for shipment.



5, Check the axial clearance. The transmission shaft along the axial direction must be able to move freely inside (1.2-1.8mm).



6, Then check whether there is any tools or equipment obstacles crusher, whether all joints and fasteners are fastened, whether there is oil leakage and other factors interfere with the broken machine start.



7, Drive shaft by hand wheel, check the broken wall and rolling mortar wall interference, whether there are other mechanical obstacles. If the broken wall impact rolling mortar wall, can see later in this chapter explain the adjustment set of adjustment.



8. Point the main motor to make sure the drive shaft is turned right. The correct turn is against the big shaft of the drive shaft. It rotates counter clockwise. The direction of rotation is fixed to the drive end of the drive shaft to determine the drive shaft can not reverse operation

                    [Click to view cone crusher parts introduction](/categories/cone-crusher-parts/)



Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd, specializing in the production of domestic and foreign brands of crusher wear spare parts manufacturers, production of domestic brands, Hua Yang, Shan Bao, SBM brands such as crusher wear parts, spare parts, as well as foreign brands, common, Sandvik, TEREX and other import brands crusher spare parts, wear parts, mining quarry companies such as crusher wear parts of choice. We achieve cost-effective localization of imported spare parts, service users at home and abroad. The company can be matched with various brands of hydraulic crusher electric parts, sealing parts, standard parts and other accessories, can meet the needs of one-stop shopping for customers at home and abroad the demand.



Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd has thirty years of production experience, and years of experience in processing export products, products have been exported to the United States, Canada, Australia, Sweden, Finland, Russia, Ukraine and Southeast Asia and other countries and regions. Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd product using the original material, high-quality raw materials, casting and heat treatment process we have a unique thirty years production experience, to ensure complete interchangeability, and original spare parts with high quality and competitive price, provide quality products, quality services for the majority of users.



Shuangfeng Qirun Machinery Parts IMP&EXP Co.,Ltd wearable parts can be customized to map, and if there is no map, the company has professional mapping personnel to help you mapping, after customization
